Membrane Vibration Tests Using Surface-Bonded Piezoelectric Patch Actuation

by National Aeronautics and Space Administration

This paper describes the status of on-going work at the NASA Langley Research Center to measure the dynamics of thin membranes. The test article is a one-meter square pre-tensioned Kapton membrane that incorporates small surface-bonded piezoelectric patches strategically positioned to excite many modes. It is shown that PVDF (polyvinylidene fluoride) and MFC (macro fiber composite) piezoelectric patch actuators provide adequate excitation energy to obtain modal frequencies and mode shapes. Results from modal tests performed on the membrane using piezoelectric patches of different sizes and positions are discussed. Gasper, James L. and Pappa, Richard S. Langley Research Center NASA/TM-2003-212150, L-18261, NAS 1.15:212150

28 pages, Paperback

Published June 20, 2018
