Technical Drawing, Plane & Solid geometry, Advanced Level: Questions & Answers

by ERICK ISANGA

This comprehensive guide is tailored specifically for students preparing for advanced-level technical drawing examinations, focusing on both plane and solid geometry. Inside, you'll find detailed graphical solutions to a wide range of topics, including:
• Geometric construction
• Circles: Construction and blending of lines and curves
• Tangents onto circles: Construction techniques
• Polygons: Construction methods
• Enlargement and reduction of plane figures, along with equivalent areas
• Scales and their applications
• Conic sections: In-depth coverage
• Isometric, orthographic, and oblique projection:
• Loci and their significance in technical drawing
• Link mechanism and cams: Practical insights
• Development by triangulation: Step-by-step guidance
• Forces in beams and frameworks: Detailed analysis
• Lines in space: Exploration and application
• Second auxiliary projection: Techniques and examples
• Further interpenetration of solid figures: Advanced concepts.

This book is exclusively designed to equip students with the essential skills and knowledge needed to excel in technical drawing examinations. Whether you're a seasoned learner or just starting out, this resource will be an invaluable tool on your path to success.

Kindle Edition

Published February 7, 2021
